Blue Diamond Flail Mower - High-Performance Mowing for Tractors (40-100 hp)

Looking for a powerful and versatile mower for your tractor? The Blue Diamond Flail Mower is the perfect solution for tractors ranging from 40 hp to 100 hp. Whether you need the Standard Duty model for Category 1 hitches or the Heavy Duty model for Category 2 hitches, this mower is built to handle tough tasks with ease.

• Powerful Cutting: Equipped with flails or hammers, the Blue Diamond Flail Mower effortlessly mows grass and brush up to 1.5 inches thick.
• Hydraulic Side Shift: Easily adjust the mower's position with the convenient hydraulic side shift feature.
• Durable Rear Roller and Rakes: Ensure a smooth and even cut with the sturdy rear roller and rakes, designed for optimal performance and longevity.

Upgrade your tractor's mowing capabilities with the Blue Diamond Flail Mower and experience efficient, high-quality mowing every time

Features

• Multi-purpose for grass and brush up to 1.5”
• Dual tapered bearing design for easy adjustment
• Minimum tractor weight of 2,000 lbs
• Counterweight recommended
• 1.5” brush capacity
• Hydraulic side shift
• Rear anti-scalp roller
• 2-year warranty

Specifications

Standard Duty

• Part Number: 403710

  • Size: 69"
  • Overall Width: 69"
  • Mowing Width: 63"
  • Tractor HP Range: 35-70
  • 3-Point Hitch Type: Category 1
  • Hydraulic Offset: 12"
  • Number of Hammers: 20
  • Weight w/out PTO: 908 lbs
  • Belts: 4

• Part Number: 403720

  • Size: 81"
  • Overall Width: 69"
  • Mowing Width: 69"
  • Tractor HP Range: 40-70
  • 3-Point Hitch Type: Category 1
  • Hydraulic Offset: 12"
  • Number of Hammers: 22
  • Weight w/out PTO: 957 lbs
  • Belts: 4

• Part Number: 403730

  • Size: 87"
  • Overall Width: 87.4"
  • Mowing Width: 80.7"
  • Tractor HP Range: 45-70
  • 3-Point Hitch Type: Category 1
  • Hydraulic Offset: 12"
  • Number of Hammers: 26
  • Weight w/out PTO: 1,063 lbs
  • Belts: 4

Heavy Duty

• Part Number: 403740

  • Size: 87"
  • Overall Width: 96"
  • Mowing Width: 87"
  • Tractor HP Range: 50-100
  • 3-Point Hitch Type: Category 2
  • Hydraulic Offset: 15"
  • Number of Hammers: 20
  • Number of Blades: 60
  • Roller Diameter: 6.69"
  • Rotor Diameter: 6.69"
  • Weight w/out PTO: 1,726 lbs
  • Belts: 4

• Part Number: 403750

  • Size: 98"
  • Overall Width: 106"
  • Mowing Width: 98"
  • Tractor HP Range: 50-100
  • 3-Point Hitch Type: Category 2
  • Hydraulic Offset: 15"
  • Number of Hammers: 24
  • Number of Blades: 72
  • Roller Diameter: 6.69"
  • Rotor Diameter: 6.69"
  • Weight w/out PTO: 1,907 lbs
  • Belts: 5
