Simply more power and more reliability. The enclosed breaker style greatly reduces vibration and noise and will drive posts so fast you'll wonder if you hit a soft spot. Multiple driver head options and tilt functionality offer versatility, and a breaker spike allows for predrilling holes in extreme conditions. Easily mount on a skid steer or excavator with the simple bolt on system.

Features

• Hydraulically driven nitrogen charged
• Fully isolated Powercell enclosed in a durable housing achieving 1000ft-lb energy class.
• Options include a domed driver head for posts 2"-8"
• Additional breaker spike for predrilling holes
• Tilt system providing 15 degrees of tilt in each direction.

Specifications

Specifications

• Weight: 1,186 – 1,656 lbs

• Width: 46"

• Height: 54"

• Energy Class: 1,000 ft-lbs

• Impact Force: 32,000 lbs-force

• Coned Driver Head Diameter: 9"

• Material Housing: ASTM A500 Grade B Tube Steel

• Depth: 18"

Design Specifications

• Driver Head Material: 4140 Steel

• Minimum Operating Pressure: 1,400 PSI

• Operating Pressure: 1,700 PSI

• Machine Lift Capacity: Minimum 1,500 lbs

• Nitrogen Charge Pressure: 250 PSI

• Tilt Angle (PDX-1000T only): 15° left & right

• Coned Driver Head Max Post Diameter: 8"
